MODULAR 100 MANUAL FILTERS

AZUD MODULAR 100 is a range of lower flow
Disc and Screen filters. Manufactured in plastic
which ensures easy maintenance, high resistance
and durability.  Flows up to 110 gpm.









ADVANTAGES

FILTER ELEMENTS
Plastic Disc filter element with threaded closure
for easy handling. This ensures the compression
of the discs and prevents accidental loss during cleaning .
Screen filter element manufactured in plastic with stainless steel screen.

LARGE FILTERING AREA RESULTS IN LESS MAINTENANCE
Allows for a reduction in the frequency and level of
maintenance. The filter elements can be removed for easy
cleaning.

ROBUSTNESS
Base and lid manufacture in high quality thermoplastic.

THREADED CLOSURE SYSTEM
Efficient from low to high pressures

GASKET SET IN THE LID
This avoids loss or wear during maintenance.

EQUIPPED WITH AUXILIARY CONNECTIONS
Lid has threaded connections, this allows easy draining or pressure relief.
Ports for Pressure Gauges molded into housing.

EASY HANDLING
No tools required for maintenance.

EASY INSTALLATION

RESISTANCE TO CHEMICAL PRODUCTS
Special gaskets available.



ADDITIONAL INFORMATION

Available with 130µ discs or screen
Maximum operating pressure:  116 psi
Maximum operating Temperature:  140°F.

 TECHNOLOGY



TECHNICAL DATA

“CLICK ON CHARTS TO ENLARGE”



DOWNLOADS

AZUD MODULAR 100:  Technical Brochure – Modular 100
